Alps Encoder with Dual Push Button and Analog Rotary Output

Model NO. : ES18A00V01

Readout Mode : Contact

Operating System : Contact Brush Type

Signal Output : Voltage Output

Axle Sleeve Type : Empty Type

Installation Form : Axle Sleeve Type

Customized : Support Customization

Factory Attributes : ODM

Transport Package : Carton

Specification : 18mm

Trademark : TAOWAVES

Origin : China

Customization : Available

Type : Rotary Encoder

Working Principle : Absolute

Contact Now

18mm Logic Encoder Metal Sleeve Encoded Rotary Digital Absolute Encoder

ES18 Series Product Specifications

1.Electrical Characteristics
Rated voltage:	DC 10V
Resistive load (Each bit):	1mA
Resolution:	8/10/12/15/16pulses/360°
Insulation resistance:	50MΩ Min at DC 250V
Dielectric strength:	1 minute at AC 50V

2.Mechanical Characteristics
Total ratational angle:	360°
Step angle:	45°
Rotational torque:	200-500gf.cm
Push-Pull Strength of shaft:	10KG
Movement of shaft:	0.35mm Max.

3.Endurance Characteristics
Rotational life:	30,000cycles
Operating temperature range:	-20ºC to+70ºC
Storage temperature range:	-40ºC to+85ºC

Our Factory
Alps Encoder with Dual Push Button and Analog Rotary Output

Application:
Alps Encoder with Dual Push Button and Analog Rotary Output

FQA:
1.What are the advantages of your factory?
Our factory has mold manufacturing workshop, plastic injection molding workshop and lathe center. 80% of the raw materials are supplied by ourselves to ensure that the quality and delivery speed are higher than those of our peers.

2.Do you support customization?
Yes, customization is supported, we need you to provide drawings, usage and requirements.

3.What is your shipping port and the term of payment ?
Ex-work or FOB Shenzhen.
30% paid in advance, 70% balance before shipment by T/T.(First transaction requires 100% payment in advance.)

4.How long is your lead time?
It will take 3workdays for samples,7-15workdays for mass production.

5.Can I get samples from you?
Small amount of samples can be provided for free, but customers need to pay for air freight themselves.

6.What's your MOQ ?
Our MOQ is 2K. If it is a small batch order, the price needs to be increased appropriately.
